3d-tiles-rendererjs-3dgs-plugin

Stream 3D Gaussian Splatting tiles into Three.js with 3d-tiles-renderer and Gaussian Splat Lite. WebGPU and WebGL2 are supported through Gaussian Splat Lite 1.0.

The plugin loads glTF/GLB tile payloads that use KHR_gaussian_splatting with KHR_gaussian_splatting_compression_spz_2. It supports explicit and implicit 3D Tiles, tile disposal and memory accounting, large GIS/ECEF coordinates, and TilesFadePlugin transitions.

[!IMPORTANT] Upgrading to 0.3? Update Gaussian Splat Lite to ^1.0.0 and Three.js to >=0.186.0. Review the renderer and raycast default changes in the 0.2.x to 0.3.x migration guide. For applications still on 0.1.x, follow the Spark-to-GSL migration guide first.

Rendering backends

The same GaussianSplatPlugin setup works with all three paths. Renderer selection, sorting, and drawing are handled by Gaussian Splat Lite; the plugin handles tile loading, transforms, fading, and disposal.

Requirements

• three@>=0.186.0
• 3d-tiles-renderer@^0.5.0
• gaussian-splat-lite@^1.0.0
• A browser with WebAssembly, Web Workers, ES modules, and WebGPU or WebGL2
• Native WebGPU requires a compatible browser/GPU and a secure context (HTTPS or localhost)

Installation

npm install 3d-tiles-rendererjs-3dgs-plugin@^0.3.0 gaussian-splat-lite@^1.0.0 three@^0.186.0 3d-tiles-renderer@^0.5.0

Quick start

WebGPU

import { Scene, PerspectiveCamera, Vector2 } from 'three';
import { WebGPURenderer } from 'three/webgpu';
import { TilesRenderer } from '3d-tiles-renderer';
import { TilesFadePlugin } from '3d-tiles-renderer/plugins';
import { GaussianSplatRenderer } from 'gaussian-splat-lite';
import { GaussianSplatPlugin } from '3d-tiles-rendererjs-3dgs-plugin';

const renderer = new WebGPURenderer({ antialias: false });
await renderer.init(); // Initialize before creating GaussianSplatRenderer.
renderer.setPixelRatio(window.devicePixelRatio);
renderer.setSize(window.innerWidth, window.innerHeight);
document.body.appendChild(renderer.domElement);

const scene = new Scene();
const camera = new PerspectiveCamera(
  60,
  window.innerWidth / window.innerHeight,
  0.1,
  10000,
);
camera.position.set(0, 0, 3); // Adjust the camera to your tileset's coordinates.

const tiles = new TilesRenderer('https://example.com/tileset.json');
tiles.setCamera(camera);
const size = new Vector2();
tiles.setResolution(camera, renderer.getSize(size));

// The application owns one scene-level Gaussian renderer.
const splatRenderer = new GaussianSplatRenderer({ renderer });
scene.add(splatRenderer);
tiles.registerPlugin(new TilesFadePlugin());
tiles.registerPlugin(new GaussianSplatPlugin());

scene.add(tiles.group);

renderer.setAnimationLoop(() => {
  tiles.update();
  renderer.render(scene, camera);
});

window.addEventListener('resize', () => {
  camera.aspect = window.innerWidth / window.innerHeight;
  camera.updateProjectionMatrix();
  renderer.setSize(window.innerWidth, window.innerHeight);
  tiles.setResolution(camera, renderer.getSize(size));
});

WebGPURenderer automatically falls back to WebGL2 when WebGPU is unavailable. The example uses setResolution(camera, renderer.getSize(size)) so it also type-checks with 3d-tiles-renderer@0.5.0, whose setResolutionFromRenderer declaration accepts only WebGLRenderer.

WebGL2

To force the WebGL2 backend of WebGPURenderer, change its constructor:

const renderer = new WebGPURenderer({ antialias: false, forceWebGL: true });
await renderer.init();

For the classic WebGL renderer, replace the WebGPU import, constructor, and initialization with:

import { WebGLRenderer } from 'three';

const renderer = new WebGLRenderer({ antialias: false });

Keep the remaining scene, tile, and GaussianSplatRenderer setup unchanged.

WebXR / VR

The Gaussian splat renderer is WebXR-aware when renderer.xr.isPresenting. WebXR applications must switch TilesRenderer between the normal camera and Three.js' XR ArrayCamera as sessions start and end. See the WebXR / VR integration guide for the complete setup.

Gaussian Splat Lite renderer

GaussianSplatPlugin does not create, configure, or dispose a GaussianSplatRenderer. Create one, retain its reference, and add it directly to the scene before rendering:

const gaussianSplatRenderer = new GaussianSplatRenderer({
  renderer,
  renderDepth: true,
});
scene.add(gaussianSplatRenderer);

tiles.registerPlugin(new GaussianSplatPlugin());

The plugin does not validate that the renderer exists. Without one, tile SplatMesh instances still load but are not drawn. Pass render settings such as blurAmount, focalAdjustment, depthTest, and renderDepth directly to Gaussian Splat Lite, not to this plugin.

renderDepth adds a companion Splat depth draw for occlusion of geometry rendered later. GSL 1.0 also provides optional stochastic, autoStochastic, and StochasticResolvePass rendering. These are renderer features and work with the tile-created Splats on WebGPU and WebGL2.

For the complete list of options, defaults, runtime properties, and on-demand rendering setup, see the GaussianSplatRenderer settings page.

Supported content

A tile is handled when:

• The tile content is gltf or glb
• The glTF scene contains KHR_gaussian_splatting
• Each Gaussian primitive uses KHR_gaussian_splatting_compression_spz_2

Raw, uncompressed Gaussian primitives and other compression schemes are not supported.

API

new GaussianSplatPlugin({
  minRaycastOpacity: 0.15,
  targetCoverageBoostScale: 0.1,
});

Public exports:

import {
  GaussianSplatPlugin,
  type GaussianSplatPluginOptions,
} from '3d-tiles-rendererjs-3dgs-plugin';

Example and development

The examples/ WebGL2 demo includes explicit and implicit sample tilesets, a globe, tileset switching, and LOD controls. Development requires Node.js 20.9 or newer.

The sample data in data/ was converted from PLY-format 3D Gaussian Splatting files with 3DGS-PLY-3DTiles-Converter.

npm install
npm start               # Run the demo with Vite
npm run check           # Type-check the package
npm run build           # Build the npm package
npm run build-examples  # Build the static demo

License

Apache-2.0
