Declarative AI agent orchestration with runtime guarantees.

_{A one-line routing change, caught before merge — fully offline (mocked LLM, stubbed tools, no API key). Source: docs/assets/gate-demo/}

agent-blueprint (CLI: abp) turns AI agent systems into versionable, testable, deployable infrastructure. You describe agents, tools, workflow graph, contracts, and policies in a single validated YAML blueprint — abp compiles it into a runnable LangGraph project and gives you the operational toolchain around it: linting, deterministic tests, eval suites, regression gates, sandboxed runs, OpenTelemetry export, and cloud deployment.

What makes ABP different is not less boilerplate — it is that everything you declare is enforced at runtime. Most agent frameworks let you describe guardrails; ABP compiles them into the generated code, so a contract in YAML and the behavior in production cannot drift apart:

And because every enforcement emits a structured trace event, the same declarations are observable (OpenTelemetry export), testable (abp test asserts on routes, state, and artifacts), and gateable (abp gate fails the PR when behavior regresses against the baseline).

If you are building a one-off demo, handwritten code is fine. If you are building agent systems that need consistency, auditability, and repeatable delivery — in CI, across a team — ABP is the stronger foundation.

pip install agent-blueprint
abp init --output my-agent.agents.yaml
abp generate my-agent.agents.yaml --target langgraph

---

Table of Contents

• How It Works
• Installation
• Quick Start
• The Operational Lifecycle
• Blueprint Schema
• CLI Reference
• Generated Project Structure
• Generation Targets
• IDE Integration
• Development
• Roadmap

---

How It Works

A blueprint flows through a strict one-way compilation pipeline:

            ┌──────────────────┐
 YAML  ───▶ │  Pydantic models  │  schema + cross-reference validation
            └────────┬─────────┘  (escalation targets, tool refs, contract refs…)
                     ▼
            ┌──────────────────┐
            │   AgentGraph IR   │  subgraph flattening, LLM resolution,
            └────────┬─────────┘  condition expression compilation
                     ▼
            ┌──────────────────┐
            │  Code generator   │  Jinja2 templates per target
            └────────┬─────────┘
                     ▼
       runnable project:  state.py · nodes.py · graph.py · tools.py · main.py
                          + _abp_trace.py (trace manifest) · _abp_harness.py
                          + _abp_otel.py (when tracing is enabled)

Around the pipeline sits the operational surface — every command is a thin CLI wrapper over a reusable logic module:

Condition expressions (state.department == 'billing') are parsed with a safe AST-based parser — no eval, no arbitrary code — and the same parser powers static analysis: route-overlap detection and loop analysis in the linter.

---

Installation

Requirements: Python 3.11+

pip install agent-blueprint

Or with pipx (recommended for CLI tools — keeps abp isolated):

pipx install agent-blueprint

Or from source:

git clone https://github.com/ahmetatar/agent-blueprint
cd agent-blueprint
pip install -e ".[dev]"

Verify:

abp --help

---

Quick Start

1. Create a blueprint

abp init --template=blueprint --output=my-agent.agents.yaml
# or scaffold a markdown request template for Codex / Claude Code:
abp init --template=spec --output=my-agent.spec.md

This creates my-agent.agents.yaml:

blueprint:
  name: "my-agent"
  version: "1.0"
  description: "A simple single-agent blueprint"

settings:
  default_model: "gpt-4o"
  default_temperature: 0.7

state:
  fields:
    messages:
      type: "list[message]"
      reducer: append

agents:
  assistant:
    model: "${settings.default_model}"
    system_prompt: |
      You are a helpful assistant.

graph:
  entry_point: assistant
  nodes:
    assistant:
      agent: assistant
      description: "Main assistant node"
  edges:
    - from: assistant
      to: END

memory:
  backend: in_memory

2. Validate and lint

abp validate my-agent.agents.yaml
abp lint my-agent.agents.yaml        # static analysis on the compiled graph
abp doctor my-agent.agents.yaml      # env vars set? impls importable? target compatible?

╭──────────────────── Valid — my-agent.agents.yaml ────────────────────╮
│   Blueprint      my-agent                                             │
│   Version        1.0                                                  │
│   Agents         1                                                    │
│   Tools          0                                                    │
│   Nodes          1                                                    │
│   Entry point    assistant                                            │
╰───────────────────────────────────────────────────────────────────────╯

3. Visualize the graph

abp inspect my-agent.agents.yaml

Outputs a Mermaid diagram you can paste into any Mermaid renderer.

4. Generate code

abp generate my-agent.agents.yaml --target langgraph

╭────────────── Generated — my-agent (langgraph) ──────────────╮
│   my-agent-langgraph/__init__.py                              │
│   my-agent-langgraph/state.py                                 │
│   my-agent-langgraph/tools.py                                 │
│   my-agent-langgraph/nodes.py                                 │
│   my-agent-langgraph/graph.py                                 │
│   my-agent-langgraph/main.py                                  │
│   my-agent-langgraph/requirements.txt                         │
│   my-agent-langgraph/.env.example                             │
╰───────────────────────────────────────────────────────────────╯

5. Run

# the short way — generates to a temp dir and executes:
abp run my-agent.agents.yaml "Hello, how are you?"

# isolated from the host — builds a container image (docker or podman)
# and runs with an allowlist-only environment:
abp run my-agent.agents.yaml "Hello, how are you?" --sandbox

# or work with the generated project directly:
cd my-agent-langgraph
pip install -r requirements.txt
cp .env.example .env   # add your OPENAI_API_KEY
python main.py "Hello, how are you?"

Sandboxing can also be declared in the blueprint (run.sandbox) so every abp run is isolated by default — see Sandboxed Runs.

---

The Operational Lifecycle

ABP's value compounds after generation. A typical blueprint lives through this loop:

 author ──▶ validate ──▶ lint / fix ──▶ doctor ──▶ test ──▶ eval ──▶ gate (CI)
   ▲                                                  │
   │                                                  ▼
   └──────────── traces export (failures → eval cases) ◀── run / deploy

1. abp test runs harness scenarios deterministically — llm_mode: mock|replay|live, tool_mode: stub|replay|live — and asserts on the final route, state, artifacts, and output contracts. Every run writes a trace manifest.
2. abp eval scores dataset-driven suites: routing accuracy, policy compliance, artifact quality rubrics.
3. abp gate is the CI merge gate: it runs both, diffs against .abp/gate-baseline.json, and fails on any regression. --update-baseline only writes when everything is green.
4. abp traces export turns failed runs into new eval cases (TDD for agents) and golden runs into locked regression tests — the dataset grows from real failures.
5. Observability is declarative: a top-level observability.tracing section exports trace events as OpenTelemetry spans to any OTLP backend. Only hashes are exported, never message content. Standard OTEL_* env vars override blueprint values; ABP_OTEL=off is the kill switch.

Deep dives: Runtime Guarantees · Gate · Traces · Sandbox · Observability · Scope

---

Blueprint Schema

A blueprint YAML has these top-level sections:

blueprint

blueprint:
  name: "my-agent"       # Required. Used for naming generated files.
  version: "1.0"         # Optional. Default: "1.0"
  description: "..."     # Optional.
  author: "..."          # Optional.
  tags: [support, nlp]   # Optional.

settings

settings:
  default_model: "gpt-4o"             # Default model for all agents
  default_model_provider: openai_gpt  # Default provider (references model_providers)
  default_temperature: 0.7
  max_retries: 3
  timeout_seconds: 300
  max_graph_steps: 25                 # maps to LangGraph recursion_limit

Variable interpolation supports two namespaces:

• ${settings.field} — resolved from the blueprint's settings section
• ${env.VAR_NAME} — resolved from environment variables at load time; if the variable is not set, the placeholder is kept as-is

state

Defines the typed state object shared across all nodes:

state:
  fields:
    messages:
      type: "list[message]"   # Built-in message list type
      reducer: append          # How concurrent updates merge: append | replace | merge
    department:
      type: string
      default: null
      enum: [billing, technical, general]
    resolved:
      type: boolean
      default: false

Reducers matter for parallel nodes: fan-out branches merge their updates through the declared reducer.

agents

agents:
  my_agent:
    name: "Friendly Name"           # Optional display name
    model: "gpt-4o"                 # or ${settings.default_model}
    model_provider: openai_gpt      # References model_providers
    system_prompt: |
      You are a helpful assistant.
    tools: [tool_a, tool_b]         # References to tools section
    temperature: 0.5
    max_tokens: 2048
    memory:
      type: conversation_buffer     # conversation_buffer | summary | vector
      max_tokens: 4000
    human_in_the_loop:
      enabled: true
      trigger: before_tool_call     # before_tool_call | after_tool_call | before_response | always
      tools: [dangerous_tool]       # Only require approval for specific tools
    llm_params:                     # Optional raw kwargs for the LangChain chat class
      timeout: 60
    reasoning:
      enabled: true                 # Mark this as a native reasoning/thinking agent
      params:                       # Raw kwargs passed through to the selected adapter
        reasoning:
          effort: high

See Model Providers for adapter selection and Reasoning Patterns for native thinking and graph-level reasoning strategies. Structured outputs belong under top-level contracts and output — not under agents.

tools

Four tool types: function, api, retrieval, and mcp (mcp: schema-only today — see status).

tools:
  classify_intent:
    type: function
    impl: "myapp.classifiers.classify_intent"   # optional: wire existing code
    description: "Classify customer intent"
    parameters:
      message:
        type: string
        required: true

  lookup_invoice:
    type: api
    method: GET
    url: "https://api.example.com/invoices/{invoice_id}"
    auth:
      type: bearer
      token_env: "BILLING_API_KEY"

See Tools for all tool types and RAG for retrievers and automatic context injection.

graph

Defines the agent workflow as a directed graph. Six node types: agent (default), function, handoff, parallel, subgraph, and supervisor.

graph:
  entry_point: router

  nodes:
    router:
      agent: router
      description: "Route requests"
      retry:
        max_attempts: 2
        backoff_seconds: 1
        on: [exception]
    handle_billing:
      agent: billing_agent
    escalate:
      type: handoff
      channel: slack            # console | webhook | slack | email
    fan_out_context:
      type: parallel
      branches: [research, pricing]
      join: merge_context
    triage:
      type: supervisor
      workers: [research, pricing]   # dynamic delegation via generated transfer tools
      max_iterations: 8
      on_finish: END
    prd_pipeline:
      type: subgraph
      ref: prd_generation_v1
      input_map:
        messages: messages
      output_map:
        prd: prd

  edges:
    # Simple edge
    - from: handle_billing
      to: END

    # Conditional routing
    - from: router
      to:
        - condition: "state.department == 'billing'"
          target: handle_billing
        - condition: "state.department == 'technical'"
          target: handle_technical
        - default: END

Condition expressions support: ==, !=, <, >, <=, >=, in, not in, and, or, not. They reference state fields with state.field_name; arbitrary names, function calls, arithmetic, and subscripts are rejected. See Condition Expressions.

Parallel nodes fan out to each branch and join at the declared join node — a real barrier; branch updates merge through the state reducers. Subgraph nodes reuse a named graph from the subgraphs registry with namespaced isolation (nesting supported, cycles detected at compile time). Supervisor nodes delegate dynamically to a declared worker set with an enforced iteration budget. Handoff nodes deliver to console/webhook/slack/email and emit handoff_requested events. See Workflow Nodes for all of them.

subgraphs:
  prd_generation_v1:
    entry_point: writer
    nodes:
      writer:
        agent: prd_writer
    edges:
      - from: writer
        to: END

contracts

Contracts make node behavior explicit, reviewable — and enforced:

contracts:
  state:
    required_fields: [messages]
    immutable_fields: [request_id]
    invariants:
      - "state.confidence >= 0"

  nodes:
    router:
      requires: [messages]
      produces: [route, confidence]
      output_contract: route_payload

  outputs:
    route_payload:
      type: object
      required: [route, confidence]
      properties:
        route: { type: string }
        confidence: { type: number }

All contract layers are enforced at runtime by the generated code: required_fields must be non-null at workflow completion, invariants are re-checked after every agent node, and violations emit contract_failed trace events before raising.

policies

policies:
  approvals:
    mode: selective          # or "all" to gate every tool call
    tools: [issue_refund]
    on_violation: block      # or "warn" to continue and emit policy_violation

  tool_usage:
    max_calls_per_node: 2
    max_calls_per_run: 5
    require_explicit_arguments: true
    on_unknown_tool: fail

  escalation:
    on_low_confidence: handoff_review
    confidence_threshold: 0.75

  budgets:
    max_tokens_per_run: 20000
    max_latency_seconds: 30
    max_cost_usd: 0.75

harness

Deterministic regression checks without hitting live models:

harness:
  defaults:
    llm_mode: mock           # mock | replay | live
    tool_mode: stub          # stub | replay | live
    seed: 42

  scenarios:
    - id: refund_happy_path
      input:
        message: "Refund invoice 123"
      expected:
        route: billing                          # node the workflow ended on (or escalated to)
        tools_called: [lookup_invoice, issue_refund]
        approvals_triggered: true
        state_assertions:                       # evaluated against the final state
          - "state.route == 'billing'"
        output_contract: refund_response        # validate stdout against contracts.outputs
        artifacts: [refund_receipt]             # artifact names that must have been written

All scenario assertions are executed by abp test — route, state_assertions, output_contract, and artifacts included. See Runtime Guarantees for real-world patterns.

evals

Benchmark-style checks over datasets instead of fixed scenarios:

evals:
  suites:
    - id: router_accuracy
      metric: exact_match
      dataset: datasets/router_cases.yaml

    - id: tool_policy_compliance
      metric: policy_violations
      dataset: datasets/policy_cases.yaml

    - id: prd_quality
      metric: rubric
      dataset: datasets/prd_cases.yaml

Rubric evals score generated artifacts with deterministic criteria (min_score, required_sections, required_terms, min_word_count).

memory

memory:
  backend: in_memory     # in_memory | sqlite | postgres | redis

See Memory & Checkpointing for backends and checkpoint strategies.

run and observability

run:
  sandbox:
    enabled: true
    engine: auto           # auto (podman → docker) | docker | podman
    network: none
    memory: 1g
    cpus: 2
    env_passthrough: [MY_EXTRA_VAR]   # secrets are allowlisted automatically

observability:
  tracing:
    enabled: true
    exporter: otlp         # otlp | console
    protocol: http/protobuf  # or grpc
    endpoint: "http://localhost:4318"
    service_name: my-agent
    sample_ratio: 1.0

Sandbox: docs/sandbox.md · Observability: docs/observability.md

---

CLI Reference

abp run

# Single-shot
abp run my-agent.yml "What is the capital of France?"

# Interactive REPL (omit input)
abp run my-agent.yml

# With options
abp run my-agent.yml --thread-id session-1 --install --env .env.local

# Inside a container (docker or podman), isolated from the host
abp run my-agent.yml "hello" --sandbox --engine podman

abp gate in CI

# .github/workflows/agents.yml (your project)
- run: abp gate my-agent.agents.yaml          # fails the PR on any regression
# after intentional changes, locally:
#   abp gate my-agent.agents.yaml --update-baseline && git add .abp/gate-baseline.json

---

Generated Project Structure

For the LangGraph target:

my-agent-langgraph/
├── __init__.py          # Package init
├── state.py             # AgentState TypedDict with reducers
├── tools.py             # Tool functions + policy/approval enforcement
├── nodes.py             # Node functions, contract checks, escalation routing
├── graph.py             # StateGraph construction with edges and routing
├── main.py              # Entrypoint: run(user_input) → str
├── _abp_trace.py        # Trace manifest emission + observer registry
├── _abp_harness.py      # Mock/stub/replay runtime helpers
├── _abp_otel.py         # OpenTelemetry bridge (only when tracing is enabled)
├── requirements.txt     # langgraph, langchain-openai, …
└── .env.example         # Required environment variables

The generated code is human-readable and fully editable. It's a starting point, not a black box — but if you stay blueprint-first, regeneration is always safe.

---

Generation Targets

ABP's blueprint schema, IR, trace schema, and harness model are deliberately framework-agnostic — but the project's priority is deepening runtime guarantees on the LangGraph target, not breadth of half-supported targets. A new target is added when it can implement the same trace and harness semantics, so blueprints and their test suites stay portable. If you want to build one, see Adding a new target framework.

---

IDE Integration (VS Code)

Export the JSON Schema and configure the YAML extension for autocompletion and inline validation:

abp schema --output blueprint-schema.json

Add to .vscode/settings.json:

{
  "yaml.schemas": {
    "./blueprint-schema.json": "*.agents.yaml"
  }
}

---

Development

git clone https://github.com/ahmetatar/agent-blueprint
cd agent-blueprint
pip install -e ".[dev]"
pre-commit install
pre-commit install --hook-type commit-msg

pytest                # full test suite
ruff check .          # lint
mypy src              # strict type check

See CONTRIBUTING.md for contribution rules, Conventional Commits, PR expectations, and testing requirements. For maintainers, Releasing covers version bump, tagging, and PyPI publishing.

Project Structure

src/agent_blueprint/
├── models/         # Pydantic v2 schema models (validation + cross-references)
├── ir/             # Intermediate representation: compiler + safe expression parser
├── generators/     # Code generators (langgraph; plain minimal)
├── templates/      # Jinja2 templates per target framework
├── cli/            # Typer CLI commands (thin wrappers)
├── linting.py      # Static checks over the compiled graph
├── doctoring.py    # Env + target-compatibility diagnostics
├── harness_runner.py / eval_runner.py / gating.py / trace_store.py
├── runners/        # abp run: local + container sandbox
├── deployers/      # Azure, AWS, GCP, Docker/Podman
└── utils/          # YAML loader (${} interpolation), Mermaid visualizer

Adding a new target framework

1. Create src/agent_blueprint/generators/<framework>.py implementing BaseGenerator
2. Add Jinja2 templates to src/agent_blueprint/templates/<framework>/
3. Register in src/agent_blueprint/cli/generate.py

The AgentGraph IR in src/agent_blueprint/ir/compiler.py is the single input to all generators — you don't touch the parser or validator. A target is considered complete when it implements the ABP trace and harness semantics, so existing harness scenarios run against it unchanged.

---

Roadmap

Done — and enforced at runtime, not just declared:

• Schema validation, ${} interpolation, safe condition expressions
• LangGraph generator: all 6 node types incl. parallel, nested subgraphs, handoff, supervisor
• Runtime-enforced contracts, approval policies, budgets, retries, escalation
• Deterministic harness (abp test) with mock/replay/live modes + full assertion surface
• Eval suites, CI regression gate, trace→eval flywheel
• Sandboxed runs (docker/podman), OpenTelemetry export
• Cloud deploy: Azure Container Apps, AWS App Runner, GCP Cloud Run, Docker/Podman
• PyPI publish (pip install agent-blueprint)

Next:

• MCP tool code generation (schema + validation already in place)
• Deeper plain-Python target or an additional framework target — gated on demand and on full trace/harness parity
• VS Code extension

---

License

MIT
